Integrated Network Analyzer
Using the Analyzer
31
part of the data acquisition board. DO NOT modify the Windows IP address
settings for the data acquisition board. You may add additional interfaces that have
their own TCP/IP protocol settings. You may need to modify other network
configurations such as WINS (the DNS server should be 192.168.111.112).
Figure 18. TCP/IP Properties for the Data Acquisition Board
<Caution
In the Windows Network setup, TCP/IP -> Internet Protocol
(TCP/IP) has a preconfigured IP address of
192.168.111.111, subnet mask of 255.255.255.0, and
gateway of 192.168.111.110. These settings MUST NOT be
changed. They are used for communication between the
data acquisition board and the Windows interface.
