OptiView
TM
Series III
Getting Started Guide
56
Supported Network Standards
Table 6. Supported Network Standards
LAN Interfaces Standard SNMP MIBs Used
IEEE 10BASE-TX,
IEEE 100BASE-TX,
IEEE 1000BASE-TX,
IEEE 1000BASE-X
RFCs: 1213, 1231, 1239, 1285, 1315,
1493, 1512, 1513, 1643, 1757, 2021,
2108, 2115, 2127, 2495, 2496, 2515,
2558
Cable Types
Unshielded Twisted Pair LAN cables (100 and 120 Ohm UTP category 3, 4, 5, 5E,
and 6 ISO/IEC Class C and D)
Foil-screened Twisted Pair cables (100 and 120 Ohm ScTP category 3, 4, 5, and 6
ISO/IEC Class C and D)
Cable Length
Measurable cable lengths are from 3 feet (.9 meter) to 500 feet (152 meters).
Within this cable length, the accuracy is +-6 feet (+-2 meters).
Note
Length accuracy is dependent upon the cable type selected in the
Cable Test screen with its ideal NVP (nominal velocity of
propagation) matching the NVP of the cable under test.
Fault Tolerance
The RJ-45 10/100/1000BASE-T Ethernet connection on the analyzer is designed
to withstand a maximum of 100 volts.
Environmental Requirements
Operating Temperature 10°C to 30°C (50°F to 86°F) with up to 95%
Relative Humidity
10°C to 40°C (50°F to 104°F) with up to 75%
Relative Humidity
Note: Battery will not charge below 12°C (53.6°F)
Non-Operating Temperature -40°C to +71°C (-40°F to +159.8°F)
Altitude Operates up to 4600 meters (15091 feet)
