Fluke PLS 3R User Manual

7
Point Laser Levels
Center Point and Accessory Mount
Center Point and Accessory Mount
Figure 1 shows features that help to layout reference marks. The vertical laser is centered 1.25 in (31.75 mm) from both
sides of the Product. To stabilize the Product and view the laser that points down, use the accessory mount to secure the
Product to the magnetic L-bracket, the oor stand, or a tripod.
31.75 mm
1.25 in
31.75 mm
1.25 in
1/4 -20
Figure 1. Center Point and Accessory Mount
