19
Point Laser Levels
Specications
Specications
3 5
Batteries
3 x AA Alkaline IEC
LR6
RBP5
3 x AA Alkaline IEC
LR6
RBP5
Battery life, continuous use, both lasers, as tested
Red
≥30 hours ≥100 hours ≥20 hours ≥70 hours
Green
≥16 hours ≥45 hours ≥9 hours ≥25 hours
*For RBP5 Rechargeable Battery please refer to the RBP5 Rechargeable Battery Pack Instructions manual.
Point laser direction
90 ° up, down, left, right 90 ° up, down, left, right, forward
Working range
≤30 m (100 ft)
Accuracy
≤3 mm at 10 m (≤1/8 in at 30 ft)
Laser leveling
4 °
Point laser diameter
≤4 mm at 5 m
Temperature
Operating
-10 °C to 50 °C (14 °F to 122 °F)
Storage
With batteries
-18 °C to 50 °C (-0.4 °F to 122 °F)
Without batteries
-20 °C to 70 °C (-13 °F to 158 °F)
Relative humidity
0 % to 90 % (0 °C to 35 °C)
0 % to 75 % (35 °C to 40 °C)
0 % to 45 % (40 °C to 50 °C)
Altitude
Operating
2000 m
Storage
12 000 m
Size (H x W x L)
116 mm x 64 mm x 104 mm (4.6 in x 2.5 in x 4.1 in)
Weight
~0.6 kg (1.3 lb)
Drop test
1 m
Safety
IEC 61010-1: Pollution Degree 2
Laser
IEC 60825-1:2014 Class 2
Light source
Semiconductor laser diode
Max output power
<1 mW
Wavelength
Red
635 nm ±5 nm
Green
525 nm ±5 nm
Electromagnetic Compatibility (EMC)
International
IEC 61326-1: Basic Electromagnetic Environment
CISPR 11: Group 1, Class A
Group 1: Equipment has intentionally generated and/or uses conductively-coupled radio frequency energy that is
necessary for the internal function of the equipment itself.
Class A: Equipment is suitable for use in all establishments other than domestic and those directly connected to a
low-voltage power supply network that supplies buildings used for domestic purposes.
There may be potential diculties in ensuring electromagnetic compatibility in other environments due to conducted
and radiated disturbances.
Korea (KCC) Class A Equipment (Industrial Broadcasting & Communication Equipment)
USA (FCC) 47 CFR 15 subpart B. This product is considered an exempt device per clause 15.103.
