ProcessMeter
Getting Acquainted with the Meter
13
Table 5. Pushbuttons (cont.)
No. Pushbutton Function(s)
C
X
M
% STEP
Measuring:
Selects a MIN, MAX, or AVG action (see pg. 18)
mA Output:
Adjusts mA output up to the next higher 25% step
D
Z
K
COARSE
Measuring:
Selects a fixed range (hold for 1 second for auto range)
mA Output:
Adjusts output up 0.1 mA
E
X
I
FINE
Measuring:
Toggles TouchHold, or in MIN MAX recording, suspends recording
mA Output:
Adjusts output up 0.001 mA
F
FINE
F
W
Measuring:
Toggles between frequency counter and ac voltage measurement functions
mA Output:
Adjusts output down 0.001 mA
G
COARSE
C
Y
Measuring:
Toggles relative reading (sets a relative zero point)
mA Output:
Adjusts output down 0.1 mA
H
% STEP
T
W
Measuring:
Toggles between Ω measure and continuity functions
mA Output:
Adjusts mA output down to the next lower 25% step
To Next Page
