ScopeMeter® Test Tool 190 Series II
Users Manual
Warning
To avoid electrical shock or fire:
xUse only the Fluke power supply, Model
BC190 (Power Adapter).
xBefore use, check that the selected/indicated
range on the BC190 matches the local line
power voltage and frequency.
xFor the BC190/808 and BC190/820 universal
Power Adapters only use line cords that
comply with the local safety regulations.
Note:
To accommodate connection to various line
power sockets, the BC190/808 and BC190/820
universal Power Adapters are equipped with a
male plug that must be connected to a line cord
appropriate for local use. Since the adapter is
isolated, the line cord does not need to be
equipped with a terminal for connection to
protective ground. Since line cords with a
protective grounding terminal are more commonly
available you might consider using these anyhow.
Warning
To avoid electrical shock or fire if a product
input is connected to more than 42 V peak
(30 Vrms) or 60 V dc:
xUse only insulated voltage probes, test leads
and adapters supplied with the product, or
indicated by Fluke as suitable for the Fluke
190 Series II ScopeMeter
®
Test Tool series.
xBefore use, inspect voltage probes, test leads
and accessories for mechanical damage and
replace when damaged.
xRemove all probes, test leads and
accessories that are not in use.
xAlways connect the power adapter first to the
ac outlet before connecting it to the product.
xDo not touch voltages >30 V ac rms, 42 V ac
peak, or 60 V dc.
xDo not connect the ground spring (figure 1,
item d) to voltages higher than 42 V peak
(30 Vrms) from earth ground.
xWhen using the ground reference lead with
any of the probes, make sure that the black
isolation sleeve (Figure 1, item. 10e) is over
the probe tip.
