Fluke T110 User Manual

Features
Model
T90 T110 T130 T150
Complies with EN 61243-3:2014
• • • •
LED Indication Range: 12 V to 690 V dc and ac
• • • •
V Display: Multiple LED Bargraph
• • • •
Independent ELV indicator LED, indicates if >50 V ac/120 V dc is present even in
the event of no battery power or main circuit failure
• • • •
LCD Indication Range: 6 V to 690 V dc and ac
• •
V Display: Digital LCD 3½ digit (1 V resolution)
• •
Resistance Measurement: LCD 3½ digit (0 to 1999 Ω/1Ω resolution)
•
LCD Backlight
• •
Display HOLD: Freeze/unfreeze display with voltage or resistance measurement
• •
CAT II 690 V / CAT III 600 V
•
CAT III 690 V / CAT IV 600 V
• • •
Rugged, Double-Insulated Wire
• • • •
Fixed Impedance ~200 kΩ (~3.5 mA @ 690 V)
• • • •
Switchable Load by 2 pushbuttons (30 mA @ 230 V)
• • •
Vibration During Load (when 2 switchable load pushbuttons are pushed)
• • •
Single-Pole Phase Test (also operates with gloves)
• • • •
Rotary Field Direction (also operates with gloves)
• • •
Continuity Test / Diode Test
• • • •
Torch
• • •
Beeper for Continuity/Phase/ACV (switchable)
• • •
Beeper for Continuity/Phase/ACV (nonswitchable)
•
IP54
•
IP64
• • •
Slim Metal Probe Tips (threaded base for included tip accessories)
• • • •
Probe Tip Protector Cap (secure storage for the docked probes)
• • • •
4 mm ∅ Probe Tip Thickness Extensions (for better t in outlets)
• • • •
19 mm Probe Tip distance when docked
• • • •
Probe Tip Sheath (UK GS38 sheath–keeps the exposed metal to a <4 mm limit)
• • • •
Slim Probe for Ultra-Compact Form Factor
•
www.calcert.com sales@calcert.com1.800.544.2843
0
5
10
15
20
25
30

Fluke T110 Specifications

General

Display type	-
Housing color	Black, Grey, Red, Yellow
AC current range	- A
AC voltage range	- V
Battery type	AAA
Number of batteries supported	2

Weight and Dimensions

Depth	38 mm
Width	70 mm
Height	260 mm
Weight	280 g
