Fluke TS 42DLX User Manual

18
TS42DLX Deluxe Test Set
Users Guide
Specifications
Electrical
Current Range (Off-
Hook)
10 mA to 100 mA
DC Resistance
Off-Hook 150 Ω nominal
On-Hook >3 MΩ
AC Impedance
Off-Hook 600 Ω nominal; 300 Hz to
3400 Hz
On-Hook >120 kΩ; 300 Hz to 3400 Hz
Rotary Dial Output
Pulsing Rate 10 pps ±1 pps
Break/Make Ratio 60/40
Interdigit Interval >300 ms
Resistance During
Break
>100 kΩ
DTMF Output
Tone Frequency
Error
±1.5 % maximum
Tone Level -3 dBm combined (typical)
High versus Low
Tone Difference
2 dB ± 2 dB
Memory Dialing
Memory Capacity 10 speed dial memories plus
one last number redial
memory
Digit Capacity 23 digits per memory
PBX Pause
Duration
User programmable;
default of 4 seconds
Hook Flash Duration User programmable;
default of 600 ms
Automatic Speaker
Shut Off Duration
User programmable;
default of 2 minutes
Battery 9 V alkaline or lithium
battery
Physical
Measurement 10 in x 3.75 in x 4.25 in
(254 mm x 96 mm x
107 mm)
Weight Less than 1.5 pounds
(0.68 kg) with one belt clip
Water Resistance Rain and moisture resistant
Environmental
Temperature Range
Operating: 29 °F to 140 °F
(-34 °C to 60 °C)
Storage -40 °F to 150 °F
(-40°C to 66 °C)
Altitude To 10,000 ft (3,000 m) max
Drop Two 20-foot drops and
twelve 12-foot drops onto
concrete.
Note
Specifications subject to change without notice.
