Visual IR Thermometer
Menu Functions
11
Menu Functions
To open the display menu, push . The menu has options for memory,
emissivity, background temperature, hot and cold markers, date, and time. For
the VT04A and VT04, menu options that are set by you are saved in memory
and remain as set each time you turn off and turn on the Product. At power on
the start-up screen briefly shows the current settings for your review.
Basic Navigation
The basic functions of the Product are accessible with the six buttons and color
display. Only five options show on the display at one time. The / buttons
scroll through the display menu. The middle option is always highlighted in
yellow. See Figure 6.
5:12
˚
C
20
˚
C
0
Yellow Highlight
Open Display Menu
Select/Enter
Up/Down to
Change Values
Battery Charge Level
hak07.eps
Figure 6. Menu Navigation and Battery Icon
