Operating Instructions FMC 25 / 60
ENGLISH
8.1 Change of FLUXTRONIC
®
, panel or seal
Unscrew the four Torx screws (torque max. 1.3 Nm)
Pull the plug of the reed sensor out of the electronic unit.
Remove the 4 Torx screws (torque max. 0.5 Nm)
Electronic
Silicone foam insulation
Panel
