Window parameters
The following table is a summary of all the windows in the single level menu structure.
Window number, function and value ranges are listed as well as the default settings that
are programmed in FPC100 before delivery.
Window Function Value/Range Default setting Own settings and
comments
00
Alarm indication.
Flashes when an
alarm is present.
Symbol
is flashing
See
PROTECTION
AND ALARM
(page
19)
01
Remaining time to
next calculated pump
start.
Standard window
during pause.
Symbol
is flashing together
with m or S.
720–15 min
900–0 s
02
Pumping time since
the latest pump start.
Standard window
when pumping.
Symbol
is flashing together
with m or S.
0–90 s
15–720 min
12–999 h
03
Pumping time since
the latest pump start
due to start on high
level
. Standard
window when
pumping after high
level.
Symbol
is flashing together
with m or S.
0–900 s
15–720 min
12–999 h
04
Measured power
in %
of the measuring
range
0–125 %
05
Measured line
voltage
0–999 V
06
Measured peak
power
in % of the
measuring range
0–125 % 0 %
DETAILED SETTINGS
Single pump controller Installation and user manual for FPC100 15
