TECHNICAL SPECIFICATIONS
Electronics
Dimension (W×H×D) 45 × 90 × 115 mm (1.77” × 3.54” × 4.53”)
Weight 0.3 kg (10.5 oz)
Supply voltage (VAC)
3 × 100-240, 3 × 380-500, 3 × 525-690
Note! UL recognized only up to 600 V
Frequency 45–65 Hz
Current input
Current transformer CT10, 25, 50 or 100
(10/25/50/100 A primary current → 55 mA secondary
current)
If current > 100 A CT10 is used with an outer standard
transformer
Power consumption Max 6 VA
Digital input, terminal 3 For a closing contact, internal supply 15–30VDC, short-
circuit current 10–20mA
Temperature input, terminal 5 Internal supply 15–30VDC, short-circuit current 2–2.5mA
Pump relay 5 A, 240 VAC Resistive. 1.5 A 240 VAC Pilot duty / AC12
Alarm relay 5 A, 240 VAC Resistive. 1.5 A 240 VAC Pilot duty / AC12
Fuse Max 10 A
Terminal wire size Use 75 °C copper (Cu) wire only. 0.2–4 mm2 single core,
0.2–2.5 mm2 flexible core, stripped length 8 mm
Terminal tightening torque 5–7 lbs-in (0.56–0.79 Nm)
Repeatability power measurement ±1 unit in window 04, 24 h, 20°C
Temperature tolerance < 0.1 % in window 04 / °C
Operating temperature range –20°C to 50°C (–4°F to 122°F)
Storage temperature range –30°C to 80°C (–22°F to 176°F)
Protection class IP20
Compliance CE and cUL
EU specifications
EMC EN50081-1, EN50082-2
Electrical safety IEC 947-5-1:1990 + A1:1994
Rated insulated voltage 690 V
Rated impulse withstand voltage 4000 V
Pollution degree 2
The terminals 3, 4 and 5 are basic insulated from the supply voltage terminals (9, 11 and
13) and the relay terminals (6, 7 and 8).
USA specifications
FCC (Federal Communications Commission)
TECHNICAL SPECIFICATIONS
22 Single pump controller Installation and user manual for FPC100
