1.2 Receiver Overview
FS-Br01 Receiver
1.3 Antenna Related
The LED status indicates the power supply state of the receiver and its working state.
This transmitter supports two antennas (internal antenna and external antenna).
1.2.1 Receiver LED Status
Three-ash-one-o（slow ash): The receiver is waiting for rmware' update or
forced rmware' update.
Three-ash-one-o（Fast ash): The rmware of the receiver is upgrading.
Fast ash:The receiver is waiting for binding or in the bind mode.
Slow ash: The LED ashes slowly when the receiver is not received the signal,
or losing signal.
Solid on: The receiver and the transmitter is conneted normally.
[7][8]
[4][5][6]
[1]
[2]
[3]
[1] RX Interface [5] +（Power anode）
[2] TX Interface [6] Signal Pin
[3] BIND Interface [7] LED
[4] -（Power cathode） [8] Antenna
