Gimbal Adjustment Instructions
Function Setup:
By adjusting the tension screws on the back of the radio,
gimbal stick can be either self-centering or non self-centering.
Screw Description
A
Adjusting screw for self-
centering/non self-centering
of the right stick
B
Stick friction adjusting screw
for non self-centering of the
right stick
C
Stick friction adjusting screw
for non self-centering of the
left stick
D
Adjusting screw for self-
centering/non self-centering
of the left stick
[A]
[B]
[C]
[D]
