Take right gimbal as example:
Attention
When the counterclockwise adjustment is
made, entire range of movement of the screw
is about 3mm. Be cautious not to adjust it too
far or the screw will fall out.
Non Self-centering to Self-centering
1. Use a Phillips screwdriver to adjust the screw [A ]
counterclockwise until the gimbal stick changes to self-
centering.
2. Adjust screw [B ]counterclockwise to adjust the Frictional
strength.
Self-centering to Non self-centering
1. Use a Phillips screwdriver to adjust the screw [A ]clockwise so
that the gimbal stick changes to non self-centering.
2. Adjust the screw [B ]clockwise to strengthen or reduce the
Frictional strength.
