Brushless ESC Introduction
1. Turn on the transmitter, move the throttle stick to the top position.
2. Connect the battery pack to ESC.
3. Wait for 2 seconds, the motor will emit special tone like “ beep-beep beep”
4. Wait for another 3 seconds, the motor will emit special tone like “123”, which means program mode entered.
Cut Off power: When the voltage drops to the set low-voltage protection threshold, the ESC will cut off the power immediately.
9.40A\50A\60A\80A\100A ESCs have adjustable SBEC 5V/6V, the default set is 5.0V.
10.Acceleration: Normal/Soft
After entering program mode, you will hear 11 tones in a loop with the following sequence.
1). “beep”
2). “beep.beep”
3). “beep.beep.beep”
4). “beep.beep.beep.beep”
5). “beep- -”
6). “beep- -.beep”
7). “beep- -.beep.beep”
8). “beep- -.beep.beep.beep”
9). “beep- -.beep.beep.beep.beep”
10).“beep- -beep- -”
11).“beep- -beep- -.beep”
SMR Function
Brake Type
Motor Timing
Motor Rotation
SR Function
Battery cells
Low Voltage Cutoff Threshold
Low Voltage Cutoff Type
BEC Voltage
Acceleration
Restore Factory Setup Defaults
(1 short tone)
(2 short tone)
(3 short tone)
(4 short tone)
(1 long tone)
(1 long 1short)
(1 long 2 short)
(1 long 3 short)
(1 long 4 short)
(2 long tone)
(2 long 1 short)
Note: 1 long “beep- -” = 5 short “beep”
Entering the programming mode
Programmable items
Set item value
Moving the throttle stick to the bottom position within 2 seconds after one kind of following tones, this item will be selected.
After the programmable item selected, then you will hear several tones in loop as follows on each programmable item, set the
value matching to a tone by moving throttle stick to top position when you hear the tone, then the motor will emit special tone
like “123”, means this value is set and saved.
For example: If you want to set the motor rotation, when you hear four short tones of "Beep", moving the throttle stick to the
bottom position within 2 seconds, means you enter the motor rotation menu. One short tone of "Beep" is forward direc-
tion(CW), two short tones of "Beep" is reverse direction(CCW). If you want to set to reverse direction(CCW), moving the
throttle stick to the top position when you hear the two short tones of "Beep", then you will hear a special confirmation tone
like “123”, which means the “CCW” is set and saved.
Keeping the throttle stick at top, you will go back to programming mode and you can select other items; or moving the stick
to bottom within 2 seconds will exit program mode directly).
Tones Programmable items
