6
Model assembly
EN
Main wing installation
1
2 3
1.Install the main wing connecting spar into the corresponding
slot on the fuselage. Attach the left and right wings to the
fuselage, ensuring that both locks have the "ON" end position
downward (the locks are open), so that the main wing could
be installed in place.
2.Press down on the locks until you hear a "click" sound,
indicating that the main wing is securely locked in place.
Installation is now complete.
2.Insert the front landing gear into the bottom hole of the fuselage, install the landing gear rocker arm into the servo rocker
arm as shown, and secure it to the landing gear aluminum part using the attached screw(HKM3.0*10 X 1).
HKM 3.0*10
