FMS CESSNA 182 - Model Assembly; Tail Wing Installation

4
Model assembly
EN
Kit contents
A: Front fuselage
B: Horizontal Stabilizer
C: Rear fuselage
D: Supporting Struts
E: Main wing set
F: Vertical Stabilizer
G: Landing gear set
H: Spars
I: Spinner
J: Propeller set
K: Scale antennas
L: Landing gear insert ,landing gear rocker arm
and screw set（HKM 3.0*10 x 7）
Tail wing installation
1.Thread the vertical tail servo wire and LED light wire
through the rear fuselage as shown, and install the
vertical tail to the slot at the rear of the fuselage.
2.Insert the horizontal tail connecting spar to the slot at
the rear of the fuselage, ensuring that the spar passes
through the hole of the plastic fastener at the bottom of
the vertical tail.
3.Install the left and right horizontal tails onto the
connecting spar, align them, and push them into the slot
at the rear of the fuselage. When there is a "click"
sound, it indicates that they are properly installed.
A.
C.
E.
F. G.
H.
I. J.
K.
L.
D.
B.
1
2 3
