5
Model assembly
EN
Main Landing Gear installation
Fuselage installation
1.Connect the servo wires of the rudder, elevator, and LED lights between the front and rear fuselages.
2.Use the attached screws (HKM3.0*10 X 2) to secure the front and rear fuselage in place from the top and bottom
directions.
1.With the bottom of the fuselage facing up, install the landing
gear set into the corresponding slot as shown.
2.Secure the landing gear set with the included screws
(HKM3.0*10 X 4) and inserts.
1.Unfasten the buckle to remove the cockpit, use a screwdriver
to remove the screws and take out the battery tray.
HKM 3.0*10
HKM 3.0*10
KA2.0*8
Front Landing Gear installation
