35Handler I, II & III Operator’s Manual - October 2008
Figure H2-5.6
Open Agitation Valve and fill tank to desired level then
close Agitation Valve. (See Figure H2-5.6)
Turn handle on Pump Suction Valve so pump is drawing
from Handler tank (recirculating).
Open Agitation Valve to complete recirculation flow. (See
Figure H2-5.6)
NOTE: Rate of flow can be controlled with Agitation
Valve and/or adjusting pump motor speed.
Figure H2-5.1
Add product to water in tank and agitate for as long as
required.
Close Agitation Valve (See Figure H2-5.6) and position the
Main Valve to bypass (This will use the pump to deliver
mixture to sprayer). (See Figure H2-5.1)
3.
4.
5.
•
6.
7.
Figure H2-5.2
If venturi delivery is preferred then close Agitation Valve,
then turn Pump Suction Valve (See Figure H2-5.8) to draw
fresh water and then turn Main Valve to venturi position.
(See Figure H2-5.2)
See Tank Cleanout instructions above
