Focusrite Clarett 8 Pre User Manual

16
CLARETT 8PRE TECHNICAL SPECIFICATIONS
Performance Specifications
Configuration
Inputs 18: analogue (8), S/PDIF (2), ADAT (8)
Outputs 20: analogue (10), S/PDIF (2), ADAT (8)
Mixer Fully assignable 30-in/16-out mixer
Digital Performance
Supported sample rates 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz & 192 kHz
Microphone Inputs
Frequency Response 20 Hz - 20 kHz +/-0.1 dB
Dynamic Range 118 dB (A-weighted)
THD+N 0.001%
Noise EIN –128 dBu (A-weighted)
Maximum input level +18 dBu
Gain Range 57 dB
Line Inputs
Frequency Response 20 Hz - 20 kHz +/-0.1 dB
Dynamic Range 118 dB
THD+N 0.005%
Maximum input level +26 dBu
Gain Range +57 dB
Instrument Inputs
Frequency Response 20 Hz - 20 kHz +/-0.1 dB
Dynamic Range 111 dB (A-weighted)
THD+N 0.001%
Maximum input level +14 dBu
Gain Range +57 dB
Line & Monitor Outputs
Dynamic Range (line outputs) 119 dB
Dynamic Range (monitor outputs) 117 dB
THD+N 0.0007%
Maximum Output Level (0 dBFS) +18 dBu, balanced
Headphone Outputs
Dynamic Range 112 dB
THD+N 0.0008%
Maximum Output Level +16 dBu

Focusrite Clarett 8 Pre Specifications

General

Type	Audio Interface
Number of Preamps	8
Connectivity	Thunderbolt
Max Sample Rate	192 kHz
Bit Depth	24-bit
Word Clock	Yes
Form Factor	Rackmount
Rack Spaces	1U
USB	No
Phantom Power	Yes
MIDI I/O	In/Out
Thunderbolt	1 x Thunderbolt
Software	Focusrite Control
Dynamic Range	118 dB (A-weighted)
Inputs	8 XLR/TRS combo (mic/line/instrument)
Outputs	8 TRS (line)
