Focusrite Clarett 8 Pre User Manual

17
Physical and Electrical Characteristics
Analogue Inputs 1 & 2
Connectors “Combo XLR” sockets: Mic/Line/Inst, on front panel
Mic/Line switching Automatic
Line/Instrument switching via Focusrite Control
Phantom power +48 V switches for inputs 1 to 4, 5 to 8
Analogue Inputs 3 to 8
Connectors “Combo XLR” sockets: Mic/Line, on rear panel
Mic/Line switching Automatic
Phantom power +48 V switches for inputs 1 to 4, 5 to 8
Analogue Outputs
Main outputs 10 x balanced ¼” TRS jacks (on rear panel)
Stereo headphone outputs 2 x ¼” TRS jack on front panel
Main monitor output level control
On front panel
Headphones level controls
Other I/O
ADAT I/O
2 x TOSLINK optical connectors:
8 channels at 44.1/48 kHz
4 channels at 88.2/96 kHz
2 channels at 176.2/192 kHz
S/PDIF I/O 2 x phono (RCA); can be re-assigned to ADAT ports in software
Word clock output BNC connector
Data connector (to Mac) 1 x Thunderbolt connector
MIDI I/O 2 x 5-pin DIN sockets
Weight and Dimensions
W x D x H
482.5 mm x 43.9 mm x 291 mm
19” x 1.73” x 11.46”
Weight
4.35 kg
9.59 lbs

Focusrite Clarett 8 Pre Specifications

General

Type	Audio Interface
Number of Preamps	8
Connectivity	Thunderbolt
Max Sample Rate	192 kHz
Bit Depth	24-bit
Word Clock	Yes
Form Factor	Rackmount
Rack Spaces	1U
USB	No
Phantom Power	Yes
MIDI I/O	In/Out
Thunderbolt	1 x Thunderbolt
Software	Focusrite Control
Dynamic Range	118 dB (A-weighted)
Inputs	8 XLR/TRS combo (mic/line/instrument)
Outputs	8 TRS (line)
