Headphone Outputs
Dynamic Range 112 dB
THD+N 0.0008%
Maximum Output Level +16 dBu
Physical and Electrical Characteristics
Analogue Inputs 1 & 2
Connectors
Mic: XLR sockets; Line: ¼” TRS jack, both on rear panel.
Inst: ¼” TS jack on front panel
Mic/Line/Instrument switching via Focusrite Control
Phantom power +48 V, independently switchable per channel
Analogue Inputs 3 to 8
Connectors Mic: XLR sockets; Line: ¼” TRS jack, both on rear panel.
Mic/Line switching via Focusrite Control
Phantom power +48 V, independently switchable per channel
Analogue Outputs
Main outputs 10 x balanced ¼” TRS jacks (on rear panel)
Stereo headphone outputs 2 x ¼” TRS jack on front panel
Main monitor output level control
On front panel
Headphones level controls
Other I/O
ADAT I/O
4 x TOSLINK optical connectors:
16 channels at 44.1/48 kHz
8 channels at 88.2/96 kHz
4 channels at 176.2/192 kHz
S/PDIF I/O 2 x phono (RCA); can be re-assigned to ADAT ports in software
Word clock output BNC connector
Data connector (to computer) 1 x Thunderbolt connector
MIDI I/O 2 x 5-pin DIN sockets
Weight and Dimensions
W x D x H
482.5 mm x 88 mm x 288 mm
19” x 3.46” x 11.34”
Weight
5.25 kg
12.13 lbs
