24
Physical and Electrical Characteristics
Analogue Inputs 1 & 2
Connectors XLR Combo type: Mic/Line/Inst, on front panel
Mic/Line switching Automatic
Line/Instrument switching Selected per channel from Focusrite Control
Pad 10 dB attenuation, selected per channel via Focusrite Control
Phantom power
Shared +48 V phantom power switch for inputs 1 & 2
(XLR connections only)
AIR function Selected per channel via Focusrite Control
Analogue Inputs 3 to 6
Connectors 4 x balanced ¼” TRS jacks on rear panel
Analogue Outputs 1 to 4
Connectors 4 x balanced ¼" TRS jacks on rear panel
Stereo headphone outputs 2 x ¼” TRS jacks on front panel
Main monitor output level control
On front panel
Headphones level controls
Other I/O
S/PDIF I/O 2 x phono (RCA)
USB 1 x USB 2.0 Type C connector
MIDI I/O 2 x 5-pin DIN sockets
Front Panel indicators
USB power Green LED
Gain Halos Tri-colour LED rings (concentric with GAIN controls)
Phantom power Red LED
Instrument mode 2 x red LEDs
AIR mode 2 x amber LEDs
Pad active 2 x green LEDs
MIDI data received Green LED
Power Green LED
