C SERIES USER’S MANUAL
21
Setting Mode Menu Definition
Button Function Description
Menu Menu Switch
Press once and enter into Set Per menu
Baud Rate Increase Press once and increase to a defined baud rate
Baud Rate Decrease Press once and decrease to a defined baud rate
Idle Speed Increase Press once the Idle Speed will increase by 50mm/s
Idle Speed Decrease Press once the Idle Speed will decrease by 50mm/s
Set Per Menu Definition
Button Function Description
Menu Menu Switch
Press once and enter into Online status
Increase Yp Scale If the actual cutting scale is smaller than the image
size from Y position, press this button will increase
the size.
Decrease Yp Scale If the actual cutting scale is larger than the image
size from Y position, press this button will decrease
the size
Increase Xp Scale If actual cutting size is smaller than the image size,
press this button will increase the size.
Decrease Xp Scale If actual cutting size is larger than the image size,
press this button will decrease the size.
6.3 Offline Status Description
Offline Keyboard Function Definition
Button Function Description
Online Online/Offline Press once to switch to online status
Y+, Left Direction Key Press and realize carriage move to left position
Y-, Right Direction Key Press and realize carriage move to right position
X+, Backwards Direction
Key
Press and realize main bearing move backwards
X-, Forwards Direction
Key
Press and realize main bearing move forwards
Original Position Setting
Key
Press once will reset X,Y to “0”, the current
position will be the original position
Test
Press for One Second
Draw/cut a tiny square
Test
Press for Two Seconds
Draw/cut a test pattern
Pause Pause/Resume
Repeat Repeat Last Time Work When the cutter finish working, press this key on
offline status will repeat the same job
Offline Status Description
