Follett 7UD100A - Detailed Dimensional Drawings

6 Undercounter Dispenser and Ice machine 7UC100A/7UD100A
Speci cations (continued) ––––––––––––––––––––––––––––––––––––––––––––––
Detailed Drawing
A
A
C
B
7UC100A 7UD100A (ADA)
A
B
C
G
L2
L1
1/4" MPT
water inlet
SIDE VIEW
BACK VIEW
FRONT VIEW
Dimension
33.50” (851 mm)
22.76” (578 mm)
22.69” (576 mm)
31.50” (800 mm)
20.76” (527mm)
20.69” (526 mm)
14.55" (370 mm)
22.05" (560 mm)
14.55" (370 mm)
2.40"
(61 mm)
2.98"
(76 mm)
3.81"
(97 mm)
4.00"
(102 mm)
NEMA 5-15
right angle
power cord
