Manual # 26-0302000-00 / Revision E ImagePRO – Multi Format Image Processor
57
Test Pattern Menu
This menu is invoked by pressing the TEST PAT button.
The type selection enables a test pattern or turns them off. The value choices are:
Off
H Ramp
V Ramp
100% Col Bars
75% Col bars
16x16 Grid
32x32 Grid
Burst
50% Gray
Gray Steps 1
Gray Steps 2
The raster box values are On or Off. Turning this value on causes the system to turn on a one-pixel border around
the output active area. This raster box includes gaps to allow the user to precisely align the input video to fill the
output raster.
TEST PATTERNS
> Type <val>
Raster Box <val>
To Next Page
