3
White Balance
Auto, Indoor, Outdoor,
One Push, Manual, VAR
Backlight
Compensation
Support
Digital Noise
Reduction
3D Digital Noise Reduction
SNR ≥55dB
Horizontal FOV 60° ~ 3.5°
Vertical FOV 35.7° ~ 2.0°
Pan Angle ±170°
Tilt Angle -30° ~ +90°
Pan Speed 1.8°/s ~ 80°/s
Tilt Speed 1.5°/s ~ 49°/s
H & V Flip Support
Image Freeze Support
PoE+ Support
Preset Position 255
Preset Accuracy 0.1°
USB Features
Operate System
Windows 7/8/10, Mac OS X,
Linux, Android
Color System/
Compression
USB 3.0 (Optional):
YUY2/H.264/H.265/MJPEG
USB 2.0:
H.264/H.265/MJPEG
Video Format
YUY2: (USB 3.0 support)
max to 1080P@30fps
USB 3.0/2.0 support:
H.264 AVC:
max to 2160P@30fps
H.265 HEVC:
max to 2160P@30fps
MJPEG:
max to 2160P@30fps
USB Audio Support
USB Video
Protocol
UVC 1.1 ~ 1.5
UVC PTZ Support
Network Features
Video
Compression
H.264/H.265/MJPEG
Video Stream
First Stream,
Second Stream
First Stream
Resolution
3840x2160, 1920x1080,
1280x720, 1024x576,
720x480, 720x408, 640x480,
640x360
Second Stream
Resolution
720x480, 720x408, 640x480,
640x360, 480x320, 320x240
Bit Rate Control CBR, VBR
Frame Rate
50Hz: 1fps ~ 50fps
60Hz: 1fps ~ 60fps
Audio
Compression
AAC
Audio Bit Rate 96Kbps, 128Kbps
Protocols
NDI®|HX2, TCP/IP, HTTP,
RTSP, RTMP/RTMPS, ONVIF,
DHCP, SRT, Multicast
Interfaces
HDMI Interface 1 x HDMI: Version 2.0
3G-SDI Interface
1 x 3G-SDI: BNC type,
800mVp-p, 75Ω. Along to
SMPTE 424M standard
LINE IN Interface
1 x LINE IN: 3.5mm Audio
Interface
Communication
Interface
1 x RS485: 3pin phoenix
port, Max Distance:
1200m, Protocol: VISCA/
Pelco-D/Pelco-P
1 x RS232 IN: 8pin Min DIN,
Max Distance: 30m,
Protocol: VISCA/Pelco-D/
Pelco-P
1 x RS232 OUT: 8pin Min
DIN, Max Distance: 30m,
Protocol: VISCA network use
USB Interface 1 x USB: Type-C
LAN(PoE+)
Interface
1 x LAN: 10M/100M/1000M
Adaptive Ethernet Port,
support PoE+
Power Jack JEITA type (DC IN 12V)
General Specifications
Tally Indicator 1
Power Indicator 1
Status Indicator 1
Restore Key 1
Power Switch 1
