FoMaKo
Focus Your Streaming www.fomako.net
4
Input Voltage DC 12V/PoE+(802.3at)
Input Current Max. 2A
Operating
Temperature
0°C ~ 40°C
Storage
Temperature
-40°C ~ 60°C
Power
Consumption
Max. 18W
Dimension 223mm x 163mm x 166mm
Net Weight About 1.8Kg
Product specifications and paramet
ers
are subject to change without notice.
4.3 Interface and Switch
Item Name
1 RESTORE Key
2 HDMI Interface
3 3G-SDI Interface
4 LINE IN Interface
5 RS485 Interface
6 USB Interface
7 RS232 OUT Interface
8 RS232 IN Interface
9 LAN(PoE+) Interface
10 DC 12V Interface
11 Power Switch
4.4 Dimension
No
t
e
RESTORE
3G-SDI
HDMI LINE IN RS485 USB OUT RS232 IN
LAN (PoE+ )
DC 12V
ON
OFF
1 3 4 5 6 7 8 92 10 11
223
133
166
42
163
62 64
Ø78
70.7
14
70.7
4-M3
1/4"-20UNC
