Ford Ranger 2020 User Manual

1.16 Towing
1.16.1 Towing Requirements
When a towing device is required, the Vehicle
Converter should use a Ford approved tow bar.
Refer to: 1.15 (page 31).
Refer to: 1.8 Jacking (page 15).
1.16.2 Towing
WARNINGS:
Do not exceed the Gross Combination
Mass (GCM) or towing capacities stated
in this section.
Ensure that the trailer towball nose
weight falls within the specified range.
For towing devices fitted by the Vehicle Converter
the following applies:
• Towing capacities must not exceed those of
the unmodified vehicle.
• Any modifications to the vehicle must be noted
in the owner's handbook or new descriptive
literature included with the owner's
documentation.
• Tow bar installations must meet the
requirements of the local design rules.
• Whenever frame drilling is necessary use tube
reinforcement.
Refer to: 5.5 Frame and Body Mounting (page
88).
1.16.3 Towing capacities
NOTE: The towing capacities below relate to
vehicles with Ford tow bars only.
NOTE: The towing capacities for Gross Vehicle
Mass (GVM), Gross Combined Mass (GCM) and
Maximum Towing Weight (MAX Tow) are listed
in Kilograms.
Towing capacities
MAX TowGCMGVMFDRRide
Height
DriveTransmissionEngine
3500600032703.55High4x46 Speed ManualI5 3.2L TDCi
3500600032703.73High4x46 Speed AutomaticI5 3.2L TDCi
2500480032003.31High4x46 Speed Manual2.0L TDCi
130PS
3500595030253.55High4x26 Speed Manual2.0L TDCi
170PS
3500600032703.55High4x46 Speed Manual2.0L TDCi
170PS
3500595030253.73High4x210 Speed Auto-
matic
2.0L TDCi
170PS
3500600032703.55High4x410 Speed Auto-
matic
2.0L TDCi
170PS
3500600032703.55High4x410 Speed Auto-
matic
2.0L TDCi
213PS
3500600032703.55High4x46 Speed Manual2.0L TDCi
213PS
2500535031303.73Ranger
Raptor
4x410 Speed Auto-
matic
2.0L TDCi
213PS
FORD RANGER 2020
Date of Publication: 09/2020
1 General Information
38
