Ford Ranger 2020 User Manual

3.2.2 Fuel Filler Mounting
CAUTION: Make sure that the filler neck
mounting bracket is made of a
conductive material, and that it provides
a grounding path for the fuel filler neck.
If the vehicle body and mounting bracket does
not provide a grounding path for the fuel filler
neck, an earth strap must be added, connecting
the filler neck to the chassis frame.
Fuel Filler Mounting Bracket
E145833
A
1
Fuel Filler Mounting Notes
DescriptionItem
The width of the bracket, where it joins the body to be at least 180 mmA
All 3x hardware fixation points on the filler neck must be utilized1
Date of Publication: 09/2020
FORD RANGER 2020
3 Powertrain
45
