Forematic F350 - Installation; Header bracket

F350/F360 doc. F05
P5
The header bracket is fixed to the door frame in the centre
of the opening. It must be set high enough for the door not
to interfere with the rail throughout the door’s travel.
Bracket height depends on the door thickness and door
roller design. Open the door to see the highest point the
door edge reaches.
Mark hole centres,
then mount the
bracket with four
suitable fixings.
The header bracket’s lower slotted mounting holes must be
at least 10mm above the highest point the door reaches.
The slotted holes can be set 200mm higher if you prefer,
but over 50mm from the ceiling.
Header bracket
INSTALLATION
