Forma Scientific, Inc.________________________________________Enviro-Scan Monitor
3-6
The user should immediately check the air filter (Figure 3-2)
and the condenser for cleanliness and the fan for proper
operation. Failure to do so may cause compressor damage and
result in loss of the freezer contents. Refer to Section 6.1,
"Cleaning the Condenser" and Section 6.2, "Cleaning the Air
Filter".
3.6 Double Door Freezer (Factory-Built Option)
Double door models of the Forma ULT freezers are available as a factory-built
option. These freezers reduce the amount of temperature loss by allowing longer term
material to be stored in the bottom portion of the freezer, and more frequently accessed,
short term material to be stored on the upper shelves. Operation of the double door freezers
is the same as single door models.
Stock # 189757 - 13 cu. ft. Models, 120 VAC
Stock # 189759 - 13 cu. ft. Models, 220 VAC
Inventory rack ordering information for 13 cu. ft. (368 Liters) Models is listed
below.
Order No. Description Max Qty per Chamber
189771 Rack includes (9) 3” boxes for top chamber 8
189795 Rack includes (12) 2” boxes for top chamber
Dimensions: 5.5” W x 9.7” H x 16.1” F-B
(14.0cm x 24.6cm x 40.9cm)
8
820009 Rack includes (9) 3” boxes for bottom chamber 8
820015 Rack includes (15) 2” boxes for bottom chamber
Dimensions: 5.5” W x 10.9” H x 16.5” F-B
(14.0cm x 27.4cm x 41.9cm)
8
3.7 Set Point Adjustment Screwdriver
A small screwdriver, located on the lower left side of the freezer frame, is used to
set the temperature Set Point. To remove the screwdriver from its holder, pull
downward on the black knob located directly below the temperature recorder
compartment. The knob is the handle of the screwdriver. Refer to Figure 3-2.
