FORST TR6 - Feed Speed Adjustment; Emergency Stopping - Standard Program

P a g e | 15
P4 shows Pre-Heat Settings
Enable Pre-Heat – True
Pre-Heat Time – 10
Crank Time – 3
Figure 6
The feed speed can be
adjusted to suit the
material being chipped see
Figure 6. Turn dial to align
number with pip. Set feed
speed so that the No-
Stress operates as
little as possible, this will
give the highest
throughput. When feeding
Leylandii or leafy material,
set feed roller speed to 4.5.
Emergency Stopping – Standard Programme
To stop engine turn off with
ignition key by turning fully
anticlockwise.
1
CONTROL VALVE FEED SPEED
ADJUSTMENT.
POSITION INDICATED BY PIP.
0 = MINIMUM
10 = MAXIMUM
Feed
speed
adjustment
