P a g e | 17
Emergency Stopping – Orange Button Programme
Push the RED SAFETY BAR. This will stop the feed rollers instantly. The chipper
flywheel will still be turning. Turn the throttle lever to idle and switch off the engine
with the ignition key.
Before using the
chipper every day
• Start the machine with the ignition key on the control panel.
• With the engine running at full speed tap the green button (3) and the rollers
will go into forward (chipping mode).
• Tap the orange button and the rollers will go into a short reverse, tap it again
and the rollers will continue in reverse.
• To stop the feed rollers push the red stop bar (1) and the rollers will stop
instantly and or push the e-stop button and whole machine will shut down.
• If any of these functions fail, turn off the machine and remove the key from the
ignition switch and contact Redwood Global and ask for service.
Feed jam & blockages
Be aware that whatever is fed into the machine has to come out of the chute.
