FORST TR6 - Engine Bay Overview; Blade Management; Blade Changing Procedure

P a g e | 29
1
OIL DIP STICK
2
ENGINE OIL FILLER CAP
3
RADIATOR FILLER CAP
4
DEBRIS SCREEN
5
RADIATOR RESERVOIR BOTTLE
6
AIR FILTER
Figure
14
1
TOP FEED ROLLER M12
SECURING SCREW HOLE
2
CHIPPING CHAMBER COVER
FIXING SCREWS
3
SIDE PANELS
4
TOP FEED ROLLER LIFTING
TOOL SOCKET
