User manual
—————————————————————————————————————–———
———————————————————————————–––––––––––––––––––––––––
Operating Manual Skiving Machine ES 50-UK-V3/24.01.2012 29 von 45
2 User manual
The Skiving machine ES 50 must be operated from the front side by one
person. The operator must be trained and made familiar with the control
elements prior to the start-up of the machine. For this purpose, Figure 9:
Details of the machine – front view (page 44) should be folded out.
The machine must only be operated with completely closed covering.
Cover plates and machine parts must not be removed during operation.
Conditions for skiving
Sharp knife edge
Smooth, undamaged guiding edge of the presser foot
Correct distance between knife edge and presser foot
Determination of the correct distance between knife and presser foot
Normal upper leather 0,3 – 0,4 mm
Fine leather 0,2 mm
Thick and hard leather 0,5 mm
Main switch
2.1
POWER
0
This switch (15) turns the main power supply on or off. The machine is
now ready for operation.
Note: Switching on this interrupter activates the knife, the aspiration, the
grinding device and possibly the drive as well according to the position
of the feed potentiometer.
The main switch is provided with an emergency stop function that
disconnects the machine completely from the main supply.
