Http Port: The default Lan port is 80.You can set another port number, such as port 8005,
8100.etc.
User&Password: Default administrator user name is admin with no password.
NOTE:
If the prompt “Subnet doesn’t match, dbclick to change!” appears, please enable DHCP set
camera’s IP address and gateway once again.
3.7 Wireless Settings
The network camera is POE-compliant, allowing transmission of power and data via a single
network cable, so here cannot allow to use Wireless function.
3.8 ADSL
Figure 3.19
If you are connecting the camera directly to a ADSL modem, you can do ADSL settings with your
ADSL account &password provided by the ISP, then make the camera connected to the network.
Figure 3.20
