Foscam R4 User Manual

76
6.1.8 UPnP always failed
UPnP only contains port forwarding in our recent software. Sometimes, it may be failed to do port
forwarding automatically because of firewall or anti-virus software. It also has much relation with router’s
security settings. So we recommend you do port forwarding manually. You can view your camera in
internet successfully after you do port forwarding manually in your router.
6.1.9 Camera can not connect wireless
If your camera could not connect wireless after you set wireless settings and plug out the cable. Please
check whether your settings are correct or not.
Normally, camera can’t connect wireless mainly because of wrong settings.
Make sure broadcast your SSID; use the same encryption for router and camera.
6.1.10 Can’t see other cameras listed in multi-device when using remote
access
If you want to view all the cameras via the WAN, verify that each camera added in the multi-device
settings can be accessed by using the DDNS name and port number. Use the DDNS domain name not
the camera’s LAN IP. (For more details see: How to add cameras in WAN)
6.2 Default Parameters
Default network Parameters
IP address: obtain dynamically
Subnet mask: obtain dynamically
Gateway: obtain dynamically
DDNS: Embedded FOSCAM domain name
Username and password
Default admin username: admin with a blank password
6.3 Specifications
ITEMS
R2
Image Sensor
Sensor Type
1/3'' CMOS
Display Resolution
1920 x 1080 (2.0 Megapixels)
Frame Rate
30fps
Min. Illumination
0 Lux (With IR Illuminator)
Lens
Lens Type
f:2.8mm,F:2.6
Angle of View
Horizontal:90°
Diagonal :110°
IR Range
13pcs IR-LEDs, IR Range up to 8m(26ft)
