Fostex VF80EX - Block Diagram

149
Specifications (VF80EX)
General
Dimensions : 307 (W) x 108 (H) x 217 (D) mm
Weight : Approx. 3.3kg
Power Supply : 120VAC 60Hz, 230V~ 50/60Hz (AC inlet type)
Power Consumption : 20W
Accessories
: Owner’s manual
: Power Cable
* Fostex Disk Management System-3
** Fostex Data In Out-1
Specifications and appearance are subject to change without notice for product improvement.
Block Diagram
TRK 1
2BAND EQ
MUTE
GAIN
PA N
EFFECT
PRE/POST
TRK 2
2BAND EQ
MUTE
GAIN
PA N
EFFECT
PRE/POST
TRK 3
2BAND EQ
MUTE
GAIN
PA N
EFFECT
PRE/POST
TRK 4
2BAND EQ
MUTE
GAIN
PA N
EFFECT
PRE/POST
TRK 5
2BAND EQ
MUTE
GAIN
PA N
EFFECT
PRE/POST
TRK 6
2BAND EQ
MUTE
GAIN
PA N
EFFECT
PRE/POST
BALANCE
GAIN
MUTE
MASTERING
EFFECT
TRK 7/8
2 TRK
MASTERING
MUTE
GAIN
to METER
SEND LEVEL
MUTE
ASP
EFFECT
PHONES
DA/C
ST OUT
L
R
DATA OUT
S/P DIF
ENCODE
AD/C
DECODE
AD/C
EFF
LR
to METER
REP 1
REP 2
REP 3
REP 4
REP 5
REP 6
REP 7
REP 8
BOUNCE
REC 8
REC 7
REC 6
REC 5
REC 4
REC 3
REC 2
REC 1
PEAK
PHANTOM (+48V)
TRIM
PHANTOM (+48V)
TRIM
PEAK
S/P DIF
DATA IN
HDR
INPUT A
INPUT B
BOUNCE
ON
OFF
ON
OFF
EFFECT
RTN LEVEL
EFFECT
