4 X-axis Aluminum Profile 20 M5*20 Flat Cap Bolt
2x
1
How to Assemble the Machine
-3-
2 Y-axis Aluminum Profile (R)
1 Y-axis Aluminum Profile (L)
Y1
Y2
8x
