Power Management Setup
ACPI (Advanced Conguration and Power Interface) is an open industry standard that denes
power and conguration management interfaces between an operating system and the BIOS.
In other words, it is a standard that describes how computer components work together
to manage system hardware. In order to use this function the ACPI specication must be
supported by the OS (for example, Windows2000 or WindowsXP).
ACPI denes ve sleeping states, they are :
S1 - The S1 sleeping state is a low wake latency sleeping state. In this state, no system
context is lost (CPU or chip set) and hardware maintains all system context. (also called
Power On Suspend)
S2 - The S2 sleeping state is a low wake latency sleeping state. This state is similar to
the S1 sleeping state except that the CPU and system cache context is lost (the OS
is responsible for maintaining the caches and CPU context). Control starts from the
processor’s reset vector after the wake event.
S3 - The S3 sleeping state is a low wake latency sleeping state where all system context is lost
except system memory. CPU, cache, and chip set context are lost in this state. Hardware
maintains memory context and restores some CPU and L2 conguration context. Control
starts from the processor’s reset vector after the wake event. (also called Suspend to
RAM)
S4 - The S4 sleeping state is the lowest power, longest wake latency sleeping state supported
by ACPI. In order to reduce power to a minimum, it is assumed that the hardware platform
has powered off all devices. Platform context is maintained. (also called Suspend to
Disk)
S5 - The S5 state is similar to the S4 state except that the OS does not save any context. The
system is in the “soft” off state and requires a complete boot when it wakes. Software
uses a different state value to distinguish between the S5 state and the S4 state to allow
for initial boot operations within the BIOS to distinguish whether or not the boot is going to
wake from a saved memory image.
Phoenix - AwardBIOS CMOS Setup Utility
Power Management Setup
ACPI Function
[Enabled] Item Help
ACPI Suspend Type
[S3(STR)]
Power Button
[Instant-off] Menu Level ►
HPET Support
[Enabled]
HPET Mode
[32-bit mode]
PWRON after PWR-Fail [Off]
** Power Management Events...
PCI Express PME [Enabled]
Wake Up by PCI Card [Enabled]
Wake Up on LAN
[Enabled]
USB Wake Up from S3
[Disabled]
Resume by Alarm
[Disabled]
Date of Month Alarm 0
Time(hh:mm:ss) Alarm 0 : 0 : 0
Power On by Mouse [Disabled]
Power On by Keyboard [Disabled]
KB Power On Password Enter
Hot Key Power On Ctrl-F1
↑↓→←:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F7: Optimized Defaults
