Foxconn A76ML-K 3.0 User Manual

1
4
1-2 Layout
1. 4-pin ATX 12V Power Connector
2. SYS_FAN Header
3. North Bridge: AMD 760G
4. PCI Express x1 Slot
5. PCI Express x16 Slot
6. PCI Slots
7. Front Audio Connector
8.CD_IN Connector
9. SPDIF_OUT Connector
10. Front USB Connectors
11. South Bridge: SB710
12. Clear CMOS Jumper
13. Speaker Connector
14. Front Panel Connector
15. SATA Connectors
16. IDE Connector
17. 24-pin ATX Power Connector
18. Chassis intrusion alarm header
19. TPM Connector
20. COM1 Connector
21. DDR3 DIMM Slots
22. CPU_FAN Header
23. CPU Socket
Note : The above motherboard layout is for reference only, please refer to the physical mother-
board for detail.
15
16
1817
19
11
13
7
1
2
4
35
8
14
23
10
6
20
9
12
21
22
