Foxconn A76ML-K 3.0 User Manual

1
2
(Continued on the next page)
1-1 Product Specications
CPU Support AM3 socket processors, Max processor power up to 95W
For the latest CPU information, please visit：
http://www.foxconnsupport.com/cpusupportlist.aspx
HyperTransport Up to 4800MT/s (HT3.0) for AM3 CPU
Chipset North Bridge: AMD 760G
South Bridge: SB710
Memory 2 x 240-pin DDR3 DIMMs
Support up to 8GB of system memory
Dual channel DDR3 1600(oc*)/1333/1066 MHz architecture
(oc*: overclocking)
Expansion Slots 1 x PCI Express x16 slot
1 x PCI Express x1 slot
2 x PCI slots
VGA Integrated ATI Radeon HD3000 GPU
Support Hybrid CrossFire
Dual Independent displays support with DVI and D-SUB
Support DirectX 10, Shader Model 4.0
Storage SB710 chipset:
-4*SATA 2.0 connectors
-300MB/S data transfer rate
-support RAID 0,1,10
-1 x IDE connector
LAN Realtek 8111E Gigabit LAN chip
Audio Realtek 662-GR audio chip:
- High Denition Audio
- 2/4/5.1-channel
- Support for S/PDIF Out
- Support Jack-Sensing function
USB Support hot plug
Support up to 12 x USB 2.0 ports (4 rear panel ports, 4 onboard USB
headers supporting 8 extra ports)
Support USB 2.0 protocol up to 480Mb/s
