3
30
Speed Adjust” item. If SPD value is faster than “Memory Speed Adjust” value, it will run at the
specied “Memory Speed Adjust” speed. Otherwise, SPD value is selected.
Select [Manual], then DRAM speed is manually selected according to the set value of “Memory
Speed Adjust”.
► Memory Speed Adjust
This item will appear only when the “Memory Speed Mode” is set to [Limit] or [Manual].
The available settings are: [800MHz], [1067MHz], [1333MHz], [1600MHz], [Auto].
► Current DRAM Speed
This item displays the current DRAM speed.
► GFX Engine Clock Override
This item allows you to enable/disable GFX Engine Clock Override support.
► PCI Express Clock Override
This option is used to adjust the speed of PCI Express slot. It may enhance the graphics card
speed.
► Spread Spectrum
If you enabled this function, it can signicantly reduce the EMI (Electromagnetic Interference)
generated by the system, so to comply with FCC regulation. But if overclocking is activated,
you had better disable it.Voltage Options
Voltage Options
► CPU Voltage Control
This option is used to change the CPU voltage in a step of 25mV. The voltage can be incre-
mented from +25mV to +775mV.
► Memory Voltage Control
This option is used to change the DRAM voltage in a step of 100mV. The voltage can be incre-
mented from +100mV to +300mV.
CMOS Setup Utility - Copyright (C) 1985-2008, American Megatrends, Inc.
Voltage Options
CPU Voltage Control Help Item
Memory Voltage Control [Disabled]
Disabled
+25mV
+50mV
+75mV
+100mV
+125mV
+150mV
+175mV
+200mV
+225mV
+250mV
+275mV
+300mV
+325mV
+350mV
Move Enter:Select +/-/:Value F10:Save ESC:Exit
F1:General Help F9:Optimized Defaults
[Disabled]
