Foxconn B75MX Series User Manual

PRODUCT INTRODUCTION
3
Internal
Connectors
1 x Front panel header
1 x Front Audio header
1 x TPM/TCM header (only for B75MX/B75MX-S/B75MX-D)
1 x LPT header
1 x INTR header (only for B75MX/B75MX-S/B75MX-D)
1xCOM2header
1 x Clear CMOS header
1 x ME header
Back Panel
Connectors
1xPS/2Keyboardport
1xPS/2Mouseport
1xRJ45LANport
1 x HDMI port (only for B75MX)
1 x DVI-D port (only for B75MX-S/B75MX-D/B75MX-D PA)
1 x VGA port
1 x COM port
2xUSB2.0ports
2xUSB3.0ports
3 x Audio ports
Hardware Monitor System voltage detection
CPU/System temperature detection
CPU/System fan speed detection
CPU Overheating warning
CPU/System fan speed control
Green Function
SupportACPI(AdvancedCongurationandPowerInterface)
Support S3(suspendtoRAM),S4(suspendtodisk)
SupportDeepS4,S5Function
Support EuP function
Bundled Software FOX ONE
FOX LiveUpdate
FOX LOGO
FOX DMI
Smart Charger
Operating System Support for Microsoft
®
Windows
®
8/7/XP
Form Factor MicroATXFormFactor,9.6inchesx7.6inches(24.3cmx19.3cm)

Foxconn B75MX Series Specifications

General

Brand	Foxconn
Model	B75MX Series
Category	Motherboard
Language	English
