Foxconn G43MX Series - Layout

1
4
1-2 Layout
8
17
22
1
9
11
24
13
7
1. 4-pin ATX 12V Power Connector
2. SYS_FAN Header
3. North Bridge: Intel
®
G43 Chipset
4. PCI Express x16 Slot
5. PCI Express x1 Slot
6. PCI Slot
7. CD_IN Connector
8. Front Audio Connector
9. S/PDIF Out Connector
10. TPM Connector
11. Front USB Connector
12. South Bridge: Intel
®
ICH10
13. Front Panel Connector
14. SATA Connector
15. Speaker Connector
16. Clear CMOS Jumper
17. 24-pin ATX Power Connector
18. Floppy Connector
19. IR/CIR Header
20. Chassis Intrusion Alarm Header
21. COM1 Connector
22. DDR2 DIMM Slot
23. CPU_FAN Header
24. CPU Socket
Note : The above motherboard layout is for reference only, please refer to the physical mother-
board for detail.
