SuperIO Conguration
► OnBoard Floppy Controller
This item is used to enable/disable Floppy Controller.
► Serial Port1
This item is used to enable/disable the onboard serial port1.
► IrDA Function
This item is used to enable/disable onboard infrared chip function.
► IrDA Duplex Mode
This item enables you to determine the transfer mode of the onboard infrared chip.Setting
values are: [Full Duplex] and [Half Duplex].
► Parallel Port Address
This item is used to assign the I/O address for the onboard parallel port.
► Parallel Port Mode
This item is used to set parallel port mode.
► Parallel Port IRQ
This item is used to assign the interrupt request (IRQ) for the onboard parallel port.
► OnBoard CIR Port
This item species the base I/O port address of the onboard Consumer IR port.
► CIR Port IRQ
When “OnBoard CIR Port” is set to [2E0]、[3E0]、[298], this item is used to allow BIOS to
select Consumer IR port IRQ.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
SuperIO Conguration
SuperIO Conguration Help Item
OnBoard Floppy Controller Allows BIOS to enable
Serial Port1 [Enabled] or disable oppy
IrDA Function [Enabled] controller.
IrDA Duplex Mode [Half Duplex]
Parallel Port Address [378]
Parallel Port Mode [Normal]
Parallel Port IRQ [IRQ7]
OnBoard CIR Port [2E0]
CIR Port IRQ [IRQ10]
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help
F9:Optimized Defaults
