1-1 Product Specications
CPU Support LGA775 socket Intel® CPU:
Core
TM
2 Quad/Core
TM
2 Extreme/Core
TM
2 Duo/
Pentium® Dual-Core/
Celeron® Dual-Core/Celeron® (Conroe-L)processors
Support 45nm processors
Front Side Bus 1600 (oc*) /1333/1066/800MHz FSB (oc* : Overclocking)
Chipset North Bridge: Intel
®
G45
South Bridge: Intel
®
ICH10 (G45M) / Intel
®
ICH10R (G45M-S)
Memory 4 x 240-pin DDR2 DIMM sockets
Support up to 16GB of system memory
Dual channel DDR2 800/667MHz architecture
Audio Realtek 8-channel audio chip
High Denition Audio
2/4/5.1/7.1-channel
Support for S/PDIF out
Support Jack-Sensing function
LAN Realtek 10/100/1000Mb/s LAN chip
Expansion Slots 1 x PCI Express x16 slot
1 x PCI Express x1 slot
2 x PCI slots
Onboard Serial ATA 6 x SATA connectors
300MB/s data transfer rate
Support hot plug and NCQ (Native Command Queuing )
USB Support hot plug
Support up to 12 x USB 2.0 ports (4 rear panel ports, 4 onboard USB
headers supporting 8 extra ports)
Supports USB 2.0 protocol up to 480Mb/s
Internal Connectors 1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x Floppy disk drive connector
6 x SATA connectors
4 x USB 2.0 connectors (supporting 8 x USB devices)
1 x CPU fan header (4-pin)
1 x System fan header (4-pin)
1 x NB fan header (4-pin)
1 x Front Panel connector
1 x CD_IN connector
1 x Front Audio connector
1 x IR/CIR connector
1 x Chassis intrusion alarm header (INTR)
1 x S/PDIF_OUT connector
1 x Speaker connector
1 x TPM connector
1 x 1394 connector (Only available in G45M-S)
