Foxconn M61PMV Series User Manual

3
32
SuperIO Devices
► OnBoard FDC Controller
This item is used to enable or disable the onboard FDC controller.
► OnBoard Serial Port 1
This item is used to assign the I/O address and interrupt request (IRQ) for the onboard serial
port COM1.
► OnBoard Serial Port 2
This item is used to assign the I/O address and interrupt request (IRQ) for the onboard serial
port COM2.
► Serial Port 2 Mode Select
This item is used to congure COM2 PORT as :
[Normal] : A RS232 device.
[IrDA] : An IrDA device for maximum 115200 bit/s.
[ASKIR] : A faster IrDA for 1152000 bit/s.
► IrDA Duplex Mode
This item enables you to determine the transfer mode of the onboard infrared chip.
► OnBoard Parallel Port
This item is used to assign the I/O address and interrupt request (IRQ) for the onboard parallel
port .
► Parallel Port Mode
This item is used to set parallel port mode.
► ECP Mode Use DMA
When “Parallel Port Mode” set to “ECP” or “ECP+EPP”, this item is used to select the the
channel of ECP mode.
Phoenix - AwardBIOS CMOS Setup Utility
SuperIO Devices
OnBoard FDC Controller
[Enabled] Item Help
OnBoard Serial Port 1
[3F8/IRQ4]
OnBoard Serial Port 2
[2F8/IRQ3] Menu Level ►
Serial Port 2 Mode Select [Normal]
x IrDA Duplex Mode Half
OnBoard Parallel Port [378/IRQ7]
Parallel Port Mode
[SPP]
x ECP Mode Use DMA 3
↑↓→←:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F7: Optimized Defaults
Enabled
"OnBoard Serial Port1" and "OnBoard Serial Port2 " must be congured to different
port and IRQ, you can set them to default values to follow PC standard.
